Yamaha HS7 Powered Studio Monitor

A high-performance, two-way bi-amplified monitor designed for professional mixing and accurate sound reproduction in the studio.

Specifications & Components:

• Speaker Type: 2-Way Bass-Reflex Bi-Amplified Nearfield Studio Monitor
• Drivers: 6.5-inch Cone Woofer (LF) and 1-inch Dome Tweeter (HF)
• Total Output Power: 95W Dynamic Power (LF: 60W / HF: 35W)
• Frequency Response: $43\text{Hz}-30\text{kHz}$ ($-10\text{dB}$)
• Crossover Frequency: $2\text{kHz}$
• Enclosure: Bass-Reflex Type, MDF Material

Key Features & Controls:

• Bi-amplified Design: Dedicated power amplifiers for the woofer ($60\text{W}$) and tweeter ($35\text{W}$) for optimal performance.
• Acoustic Control Switches:
  • ROOM CONTROL: Attenuates unnatural, exaggerated low-end that can occur when speakers are placed near walls ($0/-2/-4\text{dB}$ under $500\text{Hz}$).
  • HIGH TRIM: Provides flexible control over the high-frequency response ($\pm 2\text{dB}$ at HF).
• Inputs: Accepts balanced or unbalanced signals via $1\times \text{XLR}$ and 1×1/4′′TRS phone jack.
• Construction: Low-resonance cabinet design built with dense MDF using a three-way mitered-joint technique
